Moving Head Lights

  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light

BY-9380 BSW 380W Beam Spot Wash 3 in 1 Moving Head Light

  • BSW 380W Beam Spot Wash 3 in 1 Moving Head Light
  • INQUIRY


Electrical

Power supply: electronic auto-ranging

Input voltage range: supply 100-250V, 50/60Hz

Power consumption: 510W

ballast: electronic ballast


Optic

Light source: YODN 380U18

life expectancy: 2200 hours

Lens: High precision optical lens

Strobe: Dual lens strobe (0.5-9times/second)

Dimmer: Smooth dimmer from 0-100%

Feature

Color: wheel :13 color+white

Rotating gobo wheel: 7 gobos+ white

Static gobo wheel: 11 fixed gobos+white and effect gobo

Prism : 25and16 facets circular rotating prism

Zoom: 2.5°-65°

Focus: Linear adjustment

Frost:100% frost

Motorized

Pan/Tilt

Pan movement range: 540° Tilt movement range: 270°

8bit/16 bit movement solution, optional Automatic

Pan/Tilt position correction Pan movement 0°-540°at max…….

Tilt movement 0°-270°at max……..

LCD operation

Display: color touch screen

Supported protocols: DMX512

2 DMX modes (16/24 control channels)

Connection

DMX data in/out: Locking 3-pin XLR

AC power input: 1.5m power cord with plug


Rigging

Mounting points: 2 pairs of 1/4-turn locks

Mounting horizontally or vertically via 2 Omega brackets

Temperatures

Maximum ambient temperature: 45℃

Maximum housing temperature: 80℃

Minimum distances

Min. distance from flammable surfaces: 5.0m

Min. distance to lighted object: 2.0m
